FEATURES
|
1000PSI/PN16
|
Reduce Port
|
|
Investment Casting
|
Blow-out Proof Stem
|
|
Sanitary Design
|
PED97/23/EC(CE 0035) Approved
|
Casting Approved AD2000-W0
|
Inspection Testing: API598,EN12266
|
|
Thread: ASME B1.20.1 BS21.DIN2999/259,ISO228-1, JIS B 0203, ISO7/1
|
MATERIAL LIST
|
ITEM
|
DESIGNATION
|
MATERIAL
|
|
1
|
O-RING
|
NBR
|
|
2
|
STEM
|
SUS304
|
|
3
|
BOLT
|
SUS304
|
|
4
|
LEVER
|
ALUMINUM ALLOY
|
|
5
|
BODY
|
CF8/CF8M
|
|
6
|
CAP
|
CF8/CF8M
|
|
7
|
BALL SEAT(A)
|
RPTFE
|
|
8
|
BALL
|
CF8/CF8M
|
|
9
|
BALL SEAT(B)
|
RPTFE
|
DIMENSION TABLE
|
SIZE ITEM
|
1/4\\\\\\\'\\\\\\\'
|
3/8\\\\\\\'\\\\\\\'
|
1/2\\\\\\\'\\\\\\\'
|
3/4\\\\\\\'\\\\\\\'
|
1\\\\\\\'\\\\\\\'
|
|
D
|
7
|
7
|
9.2
|
12.5
|
15
|
|
H
|
26.5
|
26.5
|
28.3
|
31.5
|
34
|
|
W
|
22.8
|
22.8
|
22.8
|
22.8
|
22.8
|
|
L
|
50
|
50
|
58
|
70
|
83
|
|
|
|
|
| |
